L4034 Valve
3/4" Anti-Siphon, Manual (Thread)
Features:- Built-in atmospheric backflow preventer protects household water supply from possible contamination.
- Manually activates zone sprinklers with twist of handle.
- Thread connection.
Featuring a jar-top bonnet for easy access to diaphragm for quick maintenance inspections, this valve has built-in backflow prevention. The built-in prevention is designed to protect drinking and other household water from contamination.
| Type | Specification |
|---|---|
| Flow | .25 - 20 GPM |
| Inlet/Outlet | 3/4" NPT female |
| Operating Pressure | 10 - 150 PSI |
| Solenoid | 24V AC |
| Inrush | 0.40 amps |
| Holding | 0.25 amps |
